Experts in Gas Cylinders
Low-Pressure Gas Cylinders
Sharpsville Container specializes in solving complex material handling and processing needs for low pressure gas cylinders and containers. We have over 150 years in the cylinder industry and offer various high- and low-pressure gas cylinders that allow you to maximize the storage stability and shelf life of reactive gases and protect your employees.
You Are Currently Viewing
Low-Pressure Gas Cylinders
-
-
1.3L Low-Pressure Gas Cylinder
Water Volume Cu. In./ML 79/1300Diameter In./MM 3/76Length In./MM 12.25/311.2Weight Lbs./Kgs 2.25/1 -
2.4L Low-Pressure Gas Cylinder
Water Volume Cu. In./ML 146.5/2400Diameter In./MM 4.25/108Length In./MM 12.25/311.2Weight Lbs./Kgs 3.25/1.47 -
280ML Low-Pressure Gas Cylinder
Water Volume Cu. In./ML 17/280Diameter In./MM 2.81/71.44Length In./MM 3.88/98.43Weight Lbs./Kgs 0.7/0.32 -
390ML Low-Pressure Gas Cylinder
Water Volume Cu. In./ML 24/390Diameter In./MM 2.81/71.44Length In./MM 5/127Weight Lbs./Kgs 0.81/0.37 -
485ML Low-Pressure Gas Cylinder
Water Volume Cu. In./ML 30/485Diameter In./MM 3/76Length In./MM 5.25/133Weight Lbs./Kgs 1.25/.57
Applications
Low pressure gas cylinders are designed for use with nonreactive gases that store best when under minimal pressure. Their unique formation allows you to minimize storage costs and maximize volume. At Sharpsville Container, our low-pressure gas cylinders can be used for everything from calibration gasses and specialty gasses to refrigerant storage. Our cylinders are DOT-approved and are available in various sizes and customization options.
We create gas cylinders for the following industries and applications:
- Beverages
- Chemicals
- Food and dairy
- Industrial
- Pharmaceutical
- Pressurized gas.
Our Low-Pressure Gas Cylinders
Sharpsville Container offers a line of carbon steel cylinders in refillable and disposable configurations. We make our gas cylinders from 1008/1010 cold rolled steel with copper brazed in a vacuum brazing furnace. We can also create low-pressure cylinders with 240-600 psi and sizes from 25 milliliters to 2.4 liters. Our cylinders are certified by the DOT-4B and DOT-39-NRC.
We sell the following low-pressure gas cylinder models for use with calibration gasses, specialty gasses and refrigerants.
Customization Options
In addition to our line of low-pressure cylinders, we also offer customization options for sampling cylinders and integral valve cylinders. We can create any custom low pressure sampling cylinder you need with our numerous stock tooling options, including custom sizes, dip tubes, outlets and CGA fittings.
