750ML T-Series Reactive Gas Cylinder

  • Model: SST108
Water Volume Cu. In./ML 47/780
Diameter In./MM 3.25/82.6
Length In./MM 7.65/194.31
Weight Lbs./Kgs 1.75/0.8

View All Specifications

Sharpsville Container Corporation produces a Patent Pending, DOT-39 rated, disposable cylinder designed specifically for reactive gas mixtures. Using T-304 stainless steel components, this cylinder can be tailored to meet customer-specific volume requirements. The Sharpsville Container Corporation cylinders have demonstrated multiple advantages over current reactive gas cylinders. These include 1100 PSIG pressure rating, reduced seasoning time and improved gas stability by up to 56.6%, depending on the gas mixture. The combination of the above features allows our customers to improve their product offering while reducing operational costs.

Request a Quote Download Product Brochure

Specifications

Water Volume Cu. In./ML 47/780
Diameter In./MM 3.25/82.6
Length In./MM 7.65/194.31
Weight Lbs./Kgs 1.75/0.8
Threads 1"-14 UNS
Construction Straight Side
Body Material T-304 Stainless Steel
Finish Powder Coated, Standard Mill Finish
Std. Color Custom Available, Matte Silver, MILL
Std. Valve N/A, Stainless steel (Additional Charge)
Pressure Rating 1100 psig
Compliance DOT 39, Transport Canada (TC)
